Compact Pressure Transmitter (Analog) SGK/SHG series transmitter products are an economical pressure transmitter, all of which are made of imported ceramic capacitors and diffusion silicon pressure sensor chips, which are anti-overload, anti-corrosion, anti-wear, anti-impact, wide range of working temperature, good stability, high measurement accuracy, analog temperature compensation according to the user's specific temperature range and digital compensation of the full temperature range with microprocessor, and direct output of standard signals, in ic structure, exquisite design and easy installation, and is favored by users.

SGK-C series dry ceramic capacitor chip transmitter uses an alumina ceramic sensor as a "dry measurement unit", and the process pressure directly acts on the solid corrosion-resistant ceramic diaphragm, so that the diaphragm is offset, and the capacitance change outputs an electrical signal value proportional to the pressure.

SGK-S series diffusion silicon transmitter uses the piezoresistive effect of monocrystalline silicon to diffuse four equivalent strain resistors by IC process technology to form a Wheatstone bridge.

The SGK series pressure transmitter can measure the pressure, differential pressure, negative pressure, and liquid level height of the object, and can be equipped with an LCD display for easy on-site observation.

Note: These products can be customized into diaphragm flange type or diaphragm thread type Accuracy class 0.5, 0.2, 0.1 Process connection material Stainless steel 316L, agreed special materials Process interface External thread M20*1.5, external thread G1/4, external thread G1/2, flange Measurement range -0.1-60MPa Output signal Two-wire 4-20mA, three-wire 0-5V Model Specification code Description SGK SGK Product model Sensor Type S Diffused silicon sensor Pressure Type G Gauge pressure A Absolute pressure Process Connection Material 1 Stainless steel 316L (including 1.

Cr18. Hi9.

Ti and other materials) 2 Special requirements agreed upon (such as alloy aluminum, brass, Has 4 K M20×1.5 external thread F Flange (specify flange specifications DH, PH) S Special requirements agreed upon Model SGK Sensor Type 2 Analog signal 4-20mA, 2-wire 5 Analog signal 0-5V, 3-wire S Special requirements agreed upon Pressure Type H S Compact model with Horsman connector Special requirements agreed upon Field display type Accuracy level H No on-site display A Analog digital display meter Z Analog pointer display meter Explosion-proof type Measurement range 1 Class 0.1 2 Class 0.2 3 Class 0.5 Field display type i Intrinsically safe (Exia II CT6) FS Selectable range.

Please replace FS with the required range) Product structure Step 2: Refer to the screwdriver above to adjust the size of the pressure switch point, increase it in the clockwise direction and decrease it in the counterclockwise direction.
